LED light IR SMD LED 2835 850nm 90degree 20mil Epistar chip
R2835UIR850A90
Quantity
LED light IR SMD LED 2835 850nm 90degree 20mil Epistar chip
Electrical / Optical Characteristics at TA=25℃
| Parameter | Symbol | Min. | Typ. | Max. | Unit | Test Condition |
| Luminous Intensity | Ø | 128 | 135 | 158 | mW/Sr | IF=350mA |
| Viewing Angle | 2θ 1/2 | 90 | deg | IF=350mA | ||
| Spectral Line Half-Width | Δλ | 840 | 850 | 870 | nm | IF=350mA |
| Forward Voltage | VF | 1.5 | 2.0 | V | IF=350mA | |
| Reverse Current IR | IR | 10 | uA | VR=5V |
Absolute Maximum Ratings at TA=25℃
| Parameter | Maximum Rating |
| Luminous Power | 210mW |
| Peak Forward Current (1/10 Duty Cycle, 0. Lms Pulse Wisth | 350mA |
| Continuous Forward Current | 350mA |
| Reverse Voltage | 5V |
| Operating Temperature Range | -20℃ to +60℃ |
| Storage Temperature Range | -20℃ to +60℃ |
| Lead Soldering Temperature [1.6mm(.63”)From Body] | 260℃ for 5 Seconds |
