Model NO.
GP-021
Price:
$ 0.08-0.16 / piece
Minimum order quantity:
1 piece
Quantity:
  • Color Temperature(CCT):365-370nm
  • Input Voltage(V):3.0-3.4v
  • Warranty(Year):2-Year
  • Type:LAMP LED
  • Support Dimmer:No
  • Lighting solutions service:Lighting and circuitry design
  • Luminous Efficacy(lm/w):1
  • Lifespan (hours):30000
  • Working Time (hours):30000
  • Chip Material:AlGaInP
  • Emitting Color:UV
  • Luminous Intensity:UV
  • Luminous Flux(lm):UV
  • Optical Attenuation(%):1
  • Power:0.06, 0.06w
  • Power Dissipation:0.1
  • Viewing Angle(°):120
  • Color Rendering Index(Ra):70
  • Color Temperature:365-370NM
  • Operating Temperature(℃):-20 - 40
  • Storage Temperature(℃):-20 - 40
  • Place of Origin:China
  • Brand Name:CSPRING
  • Product name:3mm 365nm uv led diode
  • Emitting color:Purple
  • Wavelength:365nm
  • Lens Type:Water Clear
  • Package:1000pcs/ESD BAG
  • Forward Voltage:3.2-3.4V
  • Warranty:2 Years
  • Certification:RoHS

Through Hole Package Type Dip LEDs 0.06W F5 F3 clear lens 365nm 3mm 5mm UV LED Lamp bead 365nm

Product Description
1.Power Dissipation:100mW
2. wavelength 365/375/385/395/400nm
3. Various Emission angles:±10/20/30/60 deg.
4. Size: F3 F5

Applications
* UV curing Light Sources
* Industrial emitters
* Counterfeit Money Detection and Validation!


Cautions
(1) The LEDs emit very strong UV radiation. Do not look directly at the LEDs. UV radiation can harm your eyes. To prevent inadequate exposure of UV radiation, wear UV protective glasses.
(2) The LEDs are very sensitive to static and surge. Take a full protection against static and surge.
(3) The powered LEDs generate heat. Heat dissipation should be considered in the application design to avoid the environmental conditions for operation in excess of the absolute maximum ratings.
(4) The leads should be bent at minimum 1.5mm away from the base of header. The LEDs should be soldered at minimum 1.5mm away from the base of header.
(5) The LEDs are intended to be used for ordinary electronics equipment. Do not use the LEDs for the applications that may require a higher reliability and security and that the failure or malfunction of the LEDs may threat to life.
